MWE
COOLER MASTER MWE Bronze 550 V3
SKU: MPE-5501-ACAAW-3B
₹4200.00
₹7000.00
40% off
✓ In Stock (5 available)
Overview
MWE Bronze 550 V3 is an ATX 3.1 power supply unit designed for high temperature resilience and quiet operation.
Key Features
- 80 Plus Bronze Certified Efficiency: Ensures energy-efficient performance.
- HDB Fan: Provides quiet cooling during operation.
- Embossed Cable: For easy routing and organization in your build.
Performance
The MWE Bronze 550 V3 supports a wide range of components, offering reliable power delivery for various systems.
Basic Information
Manufacturer
COOLER MASTER
Brand
MWE
Power & Performance
Wattage
550W
Efficiency
80+ Bronze
Efficiency %
85.0%
Regulatory Certifications
cTUVus, CE, FCC
certification
80+ Bronze
efficiency_percent
85
regulatory_certifications
cTUVus, CE, FCC
Power Rails & Output
Rail Design
Single +12V Rail
Form Factor & Dimensions
Modularity
Non-Modular
Form Factor
ATX
Dimensions
L: 140mm × W: 150mm × H: 86mm
width
150
height
86
length
140
modular
Non
fan_size
120
Standards & Versions
ATX Version
ATX 3.1 (ATX 3.0 Ready)
Connectors & Ports
Power Connectors
2x 6+2-pin PCIe, 2x 4+4-pin CPU
SATA Connectors
6
Molex Connectors
3
sata
6
molex
3
Cooling & Thermal
Fan
120mm HDB
MTBF
100,000 hours
Operating Temperature
0°C ~ 40°C
fan_bearing
HDB
Electrical Input
Input Voltage
100-240V
Input Current
8-4A
Input Frequency
50-60Hz
PFC
Active
Power Good Signal
100-150ms
Hold-up Time
≥ 16ms at 100% Load
Features & Technology
Cable Type
Flat
flat_cables
False
Protection & Safety
Protections
OVP/ OPP/ SCP/ OCP/ UVP/ OTP/ Inrush Protection
ocp
True
opp
True
otp
True
ovp
True
scp
True
uvp
True
floppy
0
inrush_protection
True
Compliance & Certifications
erp_compliant
False
Memory & Storage
cable_type
Flat
input_frequency
50-60Hz
Warranty & Support
Warranty
5 years
atx3_support
True
warranty_years
5
Other Specifications
eps_8pin
0
atx_24pin
1
pcie_8pin
0
eps_4plus4
2
pcie_16pin
0
atx_version
3.1
form_factor
ATX
pcie5_ready
False
pcie_6plus2
2
single_rail
True
hold_up_time
16
input_current
8-4A
input_voltage
100-240V
zero_rpm_mode
False
power_good_signal
100-150ms
operating_temp_max
40
operating_temp_min
0
japanese_capacitors
False
life_expectancy_hours
100000
